4-Leaf Center Opening Elevator Landing Door Heavy-Duty 1200-3000mm

4-Leaf Center Opening Elevator Landing Door Heavy-Duty 1200-3000mm
4-Leaf Center Opening Elevator Landing Door Heavy-Duty 1200-3000mm
4-Leaf Center Opening Elevator Landing Door Heavy-Duty 1200-3000mm 4-Leaf Center Opening Elevator Landing Door Heavy-Duty 1200-3000mm 4-Leaf Center Opening Elevator Landing Door Heavy-Duty 1200-3000mm

큰 이미지 :  4-Leaf Center Opening Elevator Landing Door Heavy-Duty 1200-3000mm

제품 상세 정보:
Place of Origin: China
브랜드 이름: SUNNY
인증: CE,ISO9001
Model Number: SN-DM-OCM202A
결제 및 배송 조건:
Minimum Order Quantity: 1Set
가격: $500~1200
Packaging Details: container
Delivery Time: 7~15 days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 5000pcs/month
접촉

4-Leaf Center Opening Elevator Landing Door Heavy-Duty 1200-3000mm

설명
Name: 4-Leafs Center Opening Landing Door Device Product Name: 4-Leafs Center Opening Landing Door Device
JJ: 1200~3000MM Used: Elevator Parts
System: Elevator control system Door lock voltages: ≤ AC230V、≤ DC110V
Transportation: Sea Delivery Applicable: Elevator Equipment
Model: 4-Leafs Center Opening Landing Door Device Type: 4-Leafs Center Opening Landing Door Device
강조하다:

4-leaf elevator landing door

,

heavy-duty elevator door operator

,

center opening elevator door 1200-3000mm

4-Leaf Center Opening Elevator Landing Door – Heavy-Duty Smooth Operation
Product Specifications
Attribute Value
Name 4-Leafs Center Opening Landing Door Device
JJ 1200~3000MM
Application Elevator Parts
System Elevator control system
Door lock voltages ≤ AC230V、≤ DC110V
Transportation Sea Delivery
Model 4-Leafs Center Opening Landing Door Device
Key Features
  • Safety hook on door hanger prevents collision and fall off, passed 45kg soft pendulum test (GB/T7588.1/2 standard compliant)
  • Common weight self-closing type with weight located at edge of active door panel
  • Standard floor height ≥ HH+650, lowest floor height HH+500
  • Certified by NATIONAL ELEVATOR INSPECTION CENTER with CE certificate (IP20 protection level)
Technical Specifications
JJ 1200 1300 1400 1500 1600 1700 1800 1900 2000 2100 2200 2300 2400 2500 2600 2700 2800 2900 3000
A1L 1950 2100 2250 2400 2550 2700 2850 3000 3150 3300 3450 3600 3750 3900 4050 4200 4350 4500 4650
A2L 140 165 190 215 240 650 290 315 340 365 390 415 440 465 490 515 540 565 590
4-Leaf Center Opening Elevator Landing Door Heavy-Duty 1200-3000mm 0 4-Leaf Center Opening Elevator Landing Door Heavy-Duty 1200-3000mm 1 4-Leaf Center Opening Elevator Landing Door Heavy-Duty 1200-3000mm 2 4-Leaf Center Opening Elevator Landing Door Heavy-Duty 1200-3000mm 3 4-Leaf Center Opening Elevator Landing Door Heavy-Duty 1200-3000mm 4
Frequently Asked Questions
Are the elevator wire ropes durable?
Our elevator wire ropes meet special provisions and requirements. The configuration considers not only wire rope and rated load, but also traction size, resulting in tensile strength greater than the lift weight. The safety factor includes at least four wire ropes to prevent simultaneous breakage.
Is it dangerous if power fails suddenly during elevator operation?
The elevator will automatically stop using electrical and mechanical safety devices. In case of power failure, elevator brakes engage automatically. Power supply departments typically provide advance notice for planned outages.
Will users be hurt if the door closes suddenly?
The door automatically restarts if touched during closing, with no danger. Anti-pinch switches prevent closure when obstruction is detected, and closing force is carefully regulated.
How does the elevator operate?
Elevators operate via counterweight wire ropes through traction drive, moving vertically on guide rails.
Is escalator installation complicated?
Our escalators feature integrated structures for precision and efficiency, designed for easier installation and commissioning.
Do you have any certifications?
Yes, we hold ISO9001, CCC, and CE Certificates for our products.
